Double Lumen
Double lumen bronchial tube set
The double-lumen endotracheal tube (DLT), a bifurcated tube with both an endotracheal and an endobronchial lumen, is a common technique to achieve One-lung Ventilation (OLV).
Left-sided DLT and Right-sided DLT.
Suction Catheter * 2, Connector * 1 are included in Set.
Supports insertion of bronchoscope and suction catheter.
Double lumen bronchial tube set
| Type | Model | Cuff | Size (Fr) | I.D. (mm) | O.D. (short/long axis, mm) | Bronchial Cuff Φ (mm) | Tracheal Cuff Φ (mm) | Length (mm) | Material | Latex-free | Sterile |
| Left | DLT-2601 | Cuffed | 26 | 3.6 | 8.2/9.4 | 15 | 21 | 340 | DEHP-free PVC | Yes | Yes |
| DLT-2801 | Cuffed | 28 | 3.8 | 9.4/10.0 | 15 | 21 | 340 | DEHP-free PVC | Yes | Yes | |
| DLT-3201 | Cuffed | 32 | 4.5 | 10.0/11.4 | 15 | 27 | 340 | DEHP-free PVC | Yes | Yes | |
| DLT-3501 | Cuffed | 35 | 5 | 11.7/13.0 | 21 | 31 | 340 | DEHP-free PVC | Yes | Yes | |
| DLT-3701 | Cuffed | 37 | 5 | 13.0/14.0 | 21 | 31 | 340 | DEHP-free PVC | Yes | Yes | |
| DLT-3901 | Cuffed | 39 | 5.5 | 13.5/14.5 | 21 | 32 | 340 | DEHP-free PVC | Yes | Yes | |
| DLT-4101 | Cuffed | 41 | 5.5 | 14.0/15.0 | 21 | 32 | 340 | DEHP-free PVC | Yes | Yes | |
| Right | DLT-2602 | Cuffed | 26 | 3.6 | 8.2/9.4 | 15 | 21 | 340 | DEHP-free PVC | Yes | Yes |
| DLT-2802 | Cuffed | 28 | 3.8 | 9.4/10.0 | 15 | 21 | 340 | DEHP-free PVC | Yes | Yes | |
| DLT-3202 | Cuffed | 32 | 4.5 | 10.0/11.4 | 15 | 27 | 340 | DEHP-free PVC | Yes | Yes | |
| DLT-3502 | Cuffed | 35 | 5 | 11.7/13.0 | 21 | 31 | 340 | DEHP-free PVC | Yes | Yes | |
| DLT-3702 | Cuffed | 37 | 5 | 13.0/14.0 | 21 | 31 | 340 | DEHP-free PVC | Yes | Yes | |
| DLT-3902 | Cuffed | 39 | 5.5 | 13.5/14.5 | 21 | 32 | 340 | DEHP-free PVC | Yes | Yes | |
| DLT-4102 | Cuffed | 41 | 5.5 | 14.0/15.0 | 21 | 32 | 340 | DEHP-free PVC | Yes | Yes |
| PN | Type | Model | Size | Left/Right Sided | Pcs/Carton |
| H01709001 | Double lumen | DLT-2801 | 28Fr | Left | 10 |
| H01709002 | Double lumen | DLT-3201 | 32Fr | Left | 10 |
| H01709003 | Double lumen | DLT-3501 | 35Fr | Left | 10 |
| H01709004 | Double lumen | DLT-3701 | 37Fr | Left | 10 |
| H01709005 | Double lumen | DLT-3901 | 39Fr | Left | 10 |
| H01709006 | Double lumen | DLT-2802 | 28Fr | Right | 10 |
| H01709007 | Double lumen | DLT-3202 | 32Fr | Right | 10 |
| H01709008 | Double lumen | DLT-3502 | 35Fr | Right | 10 |
| H01709009 | Double lumen | DLT-3702 | 37Fr | Right | 10 |
| H01709010 | Double lumen | DLT-3902 | 39Fr | Right | 10 |
