B/V Filter
Used in anesthesia and respiratory system, our B/V Filter is designed for the protection of the patient, hospital personnel and the equipment from potential microbial contamination.
• Lightweight reduces torque on tracheal connection.
• Transparent shell for good visualization of any potential blockage.
• ISO connectors allow for safe and secure connections.
• Gas sampling port with cap for easy, safe monitoring of expired gases.
| Model | A501-1 |
| Version | Straight Adult |
| Housing Material | Polystyrene+K-Resin |
| Filtration Method | Electrostatic |
| Filtration Efficiency BFE | 99%-99.999% |
| Filtration Efficiency VFE | 99%-99.99% |
| Resistance @ 20L/min | / |
| Resistance @ 30L/min |
Pro: <1.2cm H2O (BFE99.999%, VFE99.99%) Eco: <0.6cm H2O (BFE99.9%, VFE99%) |
| Resistance @ 60L/min |
Pro: <2.6cm H2O (BFE99.999%, VFE99.99%) Eco: <1.5cm H2O (BFE99.9%, VFE99%) |
| Tidal Volume Range | 250-1500 ml |
| Effective Filtration Area | 28.26 cm2 |
| Dead Space | 32 ml |
| Connections | 22M/15F - 22F/15M |
| Sampling Port | Yes |
| Weight | 25±3g |
| Dimensions |
H: 65 ±1 mm; W: 71 ±1 mm |
| Recommended Use | ≤24h |
| PN | Model | Straight/angled | Color | Series | Luer lock | Cap | Catheter Mount | Pcs/Carton |
| H00609001 | A501-1 | Straight | Transparent | Eco | None | No cap | None | 100 |
| H00609002 | A501-1 | Straight | Transparent | Eco | Yes | White cap | None | 100 |
| H00609003 | A501-1 | Straight | Transparent | Eco | Yes | Blue tethered cap | None | 100 |
| H00609004 | A501-1 | Straight | Transparent | Eco | Yes | Green tethered cap | None | 100 |
| H00609005 | A501-1 | Straight | Transparent | Pro | Yes | White cap | None | 100 |
| H00609006 | A501-1 | Straight | Green | Eco | None | No cap | None | 100 |
| H00609007 | A501-1 | Straight | Green | Eco | Yes | White cap | None | 100 |
| H00609008 | A501-1 | Straight | Green | Eco | Yes | Green tethered cap | None | 100 |
| H00609009 | A501-1 | Straight | Green | Pro | None | No cap | None | 100 |
| H00609010 | A501-1 | Straight | Green | Pro | Yes | White cap | None | 100 |
| H00609011 | A501-1 | Straight | Transparant | Pro | Yes | White cap | Yes | 100 |
